Carbon Nanotubes Doped with 30 wt% Graphene Nanopowder/Nanoparticles
This hybrid nanomaterial combines the exceptional electrical, thermal, and structural properties of Multi Walled Carbon Nanotubes (MWCNTs) and Graphene nanoplatelets. By doping CNTs with 30 wt% graphene, the resulting material exhibits a significantly enhanced surface area, electrical conductivity, and mechanical strength.
The covalent bonding between graphene sheets and carbon nanotubes facilitates superior charge transport, making it an excellent candidate for applications such as energy storage, supercapacitors, catalysis, composite reinforcements, and nanoelectronics. Nanographenex offers this advanced composite at high quality and scalable quantities to support both research and industrial applications.
Technical Properties
30 wt% Graphene Nanopowder
| Property | Value |
|---|---|
| Purity | 99% |
| Thickness | 5 nm |
| Diameter | 1.0–12.0 µm |
| Specific Surface Area | 500–1200 m²/g |
| Electrical Conductivity | 1000–1500 S/m |
| Shape | Two-dimensional |
| Elemental Analysis (C/O) | 99.6 / 0.4 % |
Carbon Nanotubes (Multi Walled Carbon Nanotubes)
| Property | Value |
|---|---|
| Purity | > 97 wt% |
| Color | Black |
| Average Outside Diameter | > 50 nm |
| Average Inside Diameter | 5 nm |
| Length | 15–25 µm |
| Tap Density | 0.15 g/cm³ |
| True Density | ~2.4 g/cm³ |
| Specific Surface Area | > 65 m²/g |
| Ash | < 1.5 wt% |
| Electrical Conductivity | > 98 S/cm |
Applications
Carbon Nanotubes doped with Graphene nanopowders offer significant improvements in:
-
Hardness
-
Tensile strength
-
Specific strength
-
Elastic modulus
These enhancements lead to widespread use across a variety of industries and technologies, including:
-
Drug delivery
-
Biosensors
-
CNT composites
-
Catalysis
-
Nanoprobes
-
Hydrogen storage
-
Lithium-ion batteries
-
Gas-discharge tubes
-
Flat panel displays
-
Supercapacitors
-
Transistors
-
Solar cells
-
Photoluminescence systems
-
Nanostructure templates
Additional information
| Gram | 5 g, 25 g, 100 g, 500 g, 1000 g |
|---|
