Carbon Nanotubes Doped with 50 wt% Iron Oxide (Fe3O4) Nanopowder/Nanoparticles

Description

Carbon Nanotubes Doped with 50 wt% Iron Oxide (Fe₃O₄) Nanopowder/Nanoparticles

This advanced nanocomposite integrates the unique structural and conductive properties of multi-walled carbon nanotubes (MWCNTs) with the magnetic, catalytic, and electrochemical characteristics of iron oxide (Fe₃O₄) nanoparticles. By doping CNTs with 50 wt% Fe₃O₄ nanopowder, the resulting material offers a powerful synergy that enhances both mechanical and functional performance across a wide range of applications.

The Fe₃O₄ nanoparticles are near-spherical, brown-colored, and average 30 nm in diameter. With a specific surface area of 45 m²/g and 99.9% purity, these nanoparticles contribute excellent magnetic responsiveness and catalytic activity. Combined with >97 wt% pure MWCNTs—featuring high surface area, low ash content, and strong electrical conductivity—this hybrid nanomaterial is engineered for performance.

Technical Properties

Iron Oxide (Fe₃O₄) Nanopowder – 50 wt%

• Purity: 99.9%

• Average Particle Size: 30 nm

• Specific Surface Area: 45.0 m²/g

• Color: Brown

• Shape: Near spherical

Carbon Nanotubes (MWCNTs)

• Purity: > 97 wt%

• Average Outside Diameter: > 50 nm

• Average Inside Diameter: 5 nm

• Length: 15–25 µm

• Tap Density: 0.15 g/cm³

• True Density: ~2.4 g/cm³

• Specific Surface Area: > 65 m²/g

• Ash Content: < 1.5 wt%

• Electrical Conductivity: > 98 S/cm

• Color: Black

Key Applications

The fusion of Fe₃O₄ and CNTs creates a multifunctional nanomaterial ideal for next-generation devices and materials. Key improvements include increased hardness, tensile and specific strength, elastic modulus, and magneto-electrical responsiveness. Application areas include:

1. Drug Delivery – Magnetic targeting and controlled release

2. Biosensors – Enhanced signal transduction and sensitivity

3. CNT-Based Composites – Structural and functional reinforcement

4. Catalysis – Magnetic separability and increased activity

5. Nanoprobes – Magnetic navigation and precision targeting

6. Hydrogen Storage – Improved adsorption and release properties

7. Lithium Batteries – Enhanced conductivity and stability

8. Gas-Discharge Tubes – Efficient energy dissipation

9. Flat Panel Displays – Conductive layers and magnetic alignment

10. Supercapacitors – High-performance electrode materials

11. Transistors – Enhanced electron transport

12. Solar Cells – Charge transfer facilitation

13. Photoluminescence – Tunable optical properties

14. Template Materials – Functional scaffolds in nanofabrication

This material bridges the gap between structure and function, making it a valuable component for research and industrial-scale innovation.
