Description
Hafnium Diboride (HfB₂) Nanopowder
Purity: 99.5% | Average Particle Size (APS): 50 nm | Crystal Structure: Hexagonal
Product Overview
Hafnium Diboride (HfB₂) is an ultra-high-temperature ceramic material (UHTC) known for its exceptionally high melting point (~3250 °C), electrical conductivity, and oxidation resistance. As a refractory ceramic with metallic luster, HfB₂ retains strength and stability in extreme conditions, making it ideal for aerospace applications, especially in hypersonic flight systems such as nose cones and thermal protection systems.
Nano-scale HfB₂ particles offer an increased surface area and improved reactivity, enhancing their performance in composite ceramics, anti-oxidation coatings, and high-temperature electronic applications.
Technical Properties
| Property | Value |
|---|---|
| Average Particle Size (APS) | 50 nm |
| Purity (%) | 99.5 |
| BET Surface Area (m²/g) | 40.23 |
| Theoretical Density (g/cm³) | 10.5 |
| Bulk Density (g/cm³) | 0.09 |
| Melting Point (°C) | 3250 |
| Boiling Point (°C) | 5900 |
| Shape | Hexagonal |
| Color | Black Powder |
| Manufacturing Method | CVD (Chemical Vapor Deposition) |
Applications
Hafnium Diboride Nanopowder is widely used in the following high-performance and industrial sectors:
-
Thermal Protection Systems: Ideal for aerospace components exposed to extreme temperatures, such as high-speed aircraft nose cones and leading edges
-
Aerospace & Aviation: Used in ultra-high temperature ceramics in rocket and jet engines
-
Composite Ceramics: Acts as a strengthening additive in high-temperature composite materials
-
Corrosion & Oxidation Resistant Coatings: Effective as a coating for components exposed to molten metal or corrosive atmospheres
-
Crucible Linings & Chemical Equipment: Used in high-temperature chemical processing and metallurgy
-
Refractory Materials: Excellent for components exposed to intense heat and thermal shock
-
Nuclear Applications: Can be utilized as a neutron absorber due to hafnium’s strong neutron-capture capability
-
High-Efficiency Heat Conductors: Serves as a thermal conductor in demanding applications
Packaging & Storage
Hafnium Diboride nanopowder is sealed in an inert gas plastic bag and must be stored in a dry, cool, and airtight environment. Avoid exposure to moisture and air, as it may lead to oxidation and affect the powder’s dispersion and performance. Custom packaging options are available upon request.
Additional information
| Gram | 25 g, 100 g, 500 g, 1000 g |
|---|
