Hydrothermal Synthesis Autoclave Reactor with PTFE Lined Vessel – 500 mL
This 500 mL Hydrothermal Synthesis Autoclave Reactor is designed for high-pressure, high-temperature chemical synthesis. It features a robust 304 stainless steel exterior and a PTFE (Polytetrafluoroethylene) lined inner chamber, ensuring outstanding performance in aggressive chemical environments.
The PTFE lining offers excellent chemical inertness and resistance to strong acids and alkalis. With a safe operating temperature up to 180°C (maximum 240°C) and pressure resistance up to 3 MPa, it is particularly suitable for large-scale hydrothermal or solvothermal experiments in research and industrial settings.
Product Specifications
| Component | Specification |
|---|---|
| Chamber Volume | 500 mL |
| Outer Body Material | 304 Stainless Steel |
| Inner Chamber Material | PTFE |
| Total Height | 220 mm |
| Outer Body Height | 161 mm |
| Outer Body Outside Dia | 118 mm |
| Outer Body Inside Dia | 91 mm |
| Outer Body Thickness | 13.5 mm |
| PTFE Chamber Height | 136 mm |
| PTFE Chamber Outside Dia | 91 mm |
| PTFE Chamber Thickness | 8 mm |
| Upper Cap Thickness | 50 mm |
| Upper Disc Thickness | 10 mm |
| Lower Disc Thickness | 10 mm |
| SS Rod Size | 8 × 200 mm |
| Max Operating Temperature | 180°C (Tolerance: 240°C) |
| Max Working Pressure | 3 MPa |
| Heating/Cooling Rate | Recommended 5°C/min |
Key Features
Suitable for large-volume hydrothermal reactions
Smooth-threaded locking mechanism
PTFE lining ensures high acid and alkali resistance
Durable against corrosion and high pressures
Provides excellent sealing and airtight performance
Engineered for long-term use in demanding environments
Application Areas
Hydrothermal nanoparticle synthesis
Crystal growth and materials chemistry
Polymerization reactions under high pressure
Catalyst and compound synthesis
Decomposition and precipitation studies
Metal and organic compound digestion
Use in research, laboratories, and pilot production
Additional information
| Piece | 1 piece, 5 pieces |
|---|
