Description
Aluminum 6061 Alloy Powder (15–53 µm, Spherical)
Aluminum 6061 Alloy Powder is a high-strength, lightweight alloy with excellent corrosion resistance, machinability, and weldability. Produced with a spherical morphology and particle size distribution of 15–53 µm, it is optimized for powder metallurgy, additive manufacturing, and coatings.
As one of the most widely used aluminum alloys, 6061 combines magnesium (Mg), silicon (Si), copper (Cu), and chromium (Cr) with aluminum to achieve a balanced combination of mechanical performance, corrosion resistance, and thermal stability. With a tensile strength of 310 MPa, a Vickers hardness of 107 HV, and excellent thermal conductivity (167 W/m·K), Aluminum 6061 Alloy Powder is suitable for both industrial and aerospace-grade applications.
Technical Properties
Formula: Al/Mg/Si/Cu/Cr
Appearance: Silvery-gray powder
Particle Size: 15–53 µm (spherical)
Density: 2.5–2.9 g/cm³
Melting Point: 482–660 °C
Boiling Point: 2519 °C
Poisson’s Ratio: 0.33
Specific Heat: 0.896 J/g·°C
Tensile Strength (Ultimate): 310 MPa
Thermal Conductivity: 167 W/m·K
Thermal Expansion: 23.6 µm/m·°C (20–100 °C)
Vickers Hardness: 107 HV
Elemental Composition (wt%)
Si: 0.4–0.8
Mg: 0.8–1.2
Cu: 0.15–0.40
Cr: 0.04–0.35
Zn: ≤0.25
Mn: ≤0.15
Ti: ≤0.15
Fe: ≤0.7
Al: Balance
Applications
Aerospace & Defense
Aircraft fittings, structural components, and hardware requiring strength with corrosion resistance.
Automotive & Mechanical Engineering
Hydraulic pistons, brake pistons, bike frames, and mechanical couplings.
Marine & Outdoor Equipment
Marine fittings, hardware, and connectors with long-term resistance to saltwater corrosion.
Precision Engineering & Consumer Goods
Camera lens mounts, appliance fittings, decorative hardware, hinge pins, and magneto parts.
Additive Manufacturing & Powder Metallurgy
Applied in 3D printing, thermal spray coatings, and sintered components requiring a balance of machinability and toughness.
