Description
Aluminum 6061 Alloy Powder
Size: -325 mesh
Form: Silvery-Gray Powder
Product Overview
Aluminum 6061 Alloy Powder is a versatile, precipitation-hardened aluminum alloy composed primarily of aluminum, magnesium, and silicon. This alloy is renowned for its excellent corrosion resistance, moderate-to-high strength, outstanding workability, and good surface finish after processing. Thanks to its finely tuned elemental composition and uniform particle size distribution (-325 mesh), it is suitable for a wide range of structural, mechanical, and additive manufacturing applications.
This powder form enables efficient sintering, compaction, and thermal spraying, making it ideal for use in powder metallurgy, additive manufacturing (3D printing), and coating technologies.
Technical Specifications
Chemical Formula: Al/Mg/Si/Cu/Cr
Appearance: Silvery-Gray Powder
| Property | Value |
|---|---|
| Melting Point | 482–660 °C |
| Boiling Point | 2519 °C |
| Density | 2.5–2.9 g/cm³ |
| Poisson’s Ratio | 0.33 |
| Specific Heat Capacity | 0.896 J/g·°C |
| Tensile Strength (Ultimate) | 310 MPa |
| Thermal Conductivity | 167 W/m·K |
| Thermal Expansion (20–100 °C) | 23.6 µm/m·°C |
| Vickers Hardness | 107 |
Elemental Composition (% by weight)
| Element | Range |
|---|---|
| Si | 0.4–0.8% |
| Mn | ≤ 0.15% |
| Cr | 0.04–0.35% |
| Zn | ≤ 0.25% |
| Al | Balance |
| Mg | 0.8–1.2% |
| Cu | 0.15–0.40% |
| Ti | ≤ 0.15% |
| Fe | ≤ 0.7% |
Key Features
-
Excellent machinability and weldability
-
Moderate to high tensile strength
-
Excellent resistance to corrosion, especially in marine environments
-
Good thermal and electrical conductivity
-
Can be anodized for enhanced surface properties
-
Compatible with conventional powder metallurgy and AM processes
Application Areas
Aluminum 6061 Alloy Powder is widely used in:
-
Aerospace & Aviation:
Aircraft fittings, hydraulic pistons, magneto parts -
Automotive & Mechanical:
Brake pistons, couplings, valves, hardware components -
Electrical Engineering:
Connectors, heat sinks, electrical enclosures -
Consumer Products:
Bike frames, camera lens mounts, decorative hardware -
Additive Manufacturing:
3D printing and laser sintering of lightweight structural parts -
General Industry:
Appliance fittings, hinge pins, marine fittings, and more
