Calcium Copper Titanate (CaCu₃Ti₄O₁₂, CCTO) Micron Powder
Purity: ≥ 99.5%
Average Particle Size (D50): 1–3 µm
Product Description
Calcium Copper Titanate (CaCu₃Ti₄O₁₂), commonly referred to as CCTO, is a ceramic oxide material known for its exceptionally high dielectric constant—exceeding 10,000 at room temperature. With a cubic crystal structure and excellent chemical stability, CCTO is widely researched and used in next-generation capacitive and energy storage systems.
The material’s unique dielectric properties are attributed to internal barrier layer mechanisms, making it especially valuable for dynamic random-access memory (DRAM) components, multilayer ceramic capacitors (MLCCs), embedded passive devices, and high-energy density capacitors.
Chemical & Physical Properties
| Property | Value |
|---|---|
| Chemical Formula | CaCu₃Ti₄O₁₂ |
| Appearance | Brown solid powder |
| Density | 4.7 g/cm³ |
| Molar Mass | 614.18 g/mol |
| Crystal Structure | Cubic |
| Melting Point | >1000 °C |
Elemental Composition (Typical):
| Component | Content (wt%) |
|---|---|
| Purity (Total) | ≥ 99.5% |
| Fe₂O₃ | < 0.01% |
| SrO | < 0.05% |
| Na₂O + K₂O | < 0.01% |
| Al₂O₃ | < 0.10% |
| SiO₂ | < 0.10% |
| H₂O | < 0.50% |
| Ignition Loss | < 1.00% |
Key Features
-
Ultra-high dielectric constant (εᵣ > 10,000 at RT)
-
High thermal and chemical stability
-
Cubic perovskite-like structure
-
Excellent electrical insulating properties
-
High purity and controlled particle size (1–3 µm D50)
-
Low ionic impurity content (Fe, Na, Sr, etc.)
Applications
CCTO Micron Powder is used in advanced ceramic, electronic, and energy storage technologies:
-
High Dielectric Ceramic Capacitors (MLCCs)
-
DRAM Modules and Embedded Passive Devices
-
Electroceramic Resistors
-
Next-Generation Energy Storage Devices
-
New Energy Battery Systems:
-
Lithium-ion, solid-state, and solar cell battery components
-
Battery separators and electrodes for electric vehicles
-
-
Photovoltaics and Solar Energy Systems
-
Functional Fillers in Polymers for Dielectric Enhancement
Additional information
| Gram | 25 g, 100 g, 500 g, 1000 g |
|---|
