CoCrMo (Cobalt-Chrome-Molybdenum) Alloy Micron Powder for Additive Manufacturing, Size: 15-45 µm, Spherical

Description

CoCrMo Alloy Micron Powder for Additive Manufacturing, Size: 15-45 µm, Spherical

CoCrMo Alloy Micron Powder for Additive Manufacturing is a premium-grade biocompatible cobalt-chromium-molybdenum spherical powder specifically engineered for advanced 3D metal printing technologies. With a precisely controlled particle size distribution of 15-45 µm, this high-performance alloy powder delivers exceptional results in Selective Laser Melting (SLM), Direct Metal Laser Sintering (DMLS), Electron Beam Melting (EBM), and binder jetting processes.

Our CoCrMo powder (Co-28Cr-6Mo) is designed to meet the stringent requirements of ASTM F75 and ISO 5832-4 medical device standards, making it the preferred choice for orthopedic implants, dental prosthetics, and surgical instruments. The spherical morphology ensures superior flowability, uniform powder bed distribution, and high packing density—achieving ≥99.5% relative density in as-built parts with minimal porosity.

This cobalt-chrome alloy powder exhibits outstanding mechanical properties with a tensile strength of 1110 ± 30 MPa and yield strength of 690 ± 15 MPa, combined with excellent wear resistance, corrosion resistance, and biocompatibility. The molybdenum content enhances resistance to pitting corrosion in physiological environments, while chromium provides a stable passive oxide layer for long-term implant performance.

The CoCrMo spherical powder maintains consistent particle size distribution, low oxygen content, and high sphericity ratio—critical factors for producing patient-specific implants, complex anatomical structures, and high-precision medical devices through metal additive manufacturing.

Physical and Morphological Characteristics

Particle Size and Quality:

• Particle Size Distribution: 15-45 µm (optimized for laser powder bed fusion)
• Particle Morphology: Spherical (high sphericity >95%)
• Powder Density: ≥99.5% relative density in as-built parts
• Flowability: Excellent (Hall flow <35s/50g)
• Apparent Density: 4.5-5.0 g/cm³
• Tap Density: High packing efficiency
• Oxygen Content: <500 ppm (controlled atmosphere production)

Chemical Composition (wt%)

CoCrMo Alloy Composition (ASTM F75 / ISO 5832-4 Compliant):

• Cobalt (Co): Balance (63-66%)
• Chromium (Cr): 28%
• Molybdenum (Mo): 6%
• Nickel (Ni): <0.5% max
• Iron (Fe): <0.75% max
• Carbon (C): <0.35% max
• Silicon (Si): <1.0% max
• Manganese (Mn): <1.0% max

Mechanical Properties (As-Built AM Parts)

Superior Strength and Performance:

• Yield Strength (0.2% offset): 690 ± 15 MPa
• Ultimate Tensile Strength (UTS): 1110 ± 30 MPa
• Elongation at Break: 19 ± 2%
• Hardness: 380-420 HV (as-built), up to 520 HV (heat treated)
• Elastic Modulus: 210-240 GPa
• Fatigue Strength: Excellent (suitable for load-bearing applications)
• Fracture Toughness: High impact resistance

Advanced Material Properties

Biocompatibility and Medical Certifications:

• FDA Approved: Class II medical device material
• ISO 10993 Compliant: Cytotoxicity, sensitization, irritation tested
• ASTM F75 Standard: Surgical implant quality
• ISO 5832-4 Compliant: Cast CoCrMo alloy for surgical implants
• Biocompatible: Proven long-term implantation success
• Non-magnetic: MRI compatible

Corrosion and Wear Resistance:

• Outstanding corrosion resistance in body fluids and saline environments
• Excellent resistance to pitting and crevice corrosion
• Superior wear resistance (low friction coefficient)
• Passive oxide layer formation (Cr₂O₃)
• High resistance to fretting corrosion
• Stable in aggressive chemical environments

Thermal and Physical Properties:

• Density: 8.3-8.5 g/cm³
• Melting Point: 1350-1450°C
• Thermal Conductivity: 14-15 W/m·K
• Coefficient of Thermal Expansion: 14.0 × 10⁻⁶ /°C
• High Temperature Stability: Maintains properties up to 600°C

Manufacturing and Processing Advantages

Additive Manufacturing Benefits:

• Excellent laser absorption for SLM/DMLS processes
• Minimal spatter and smoke during printing
• Low residual stress in as-built parts
• Good support removal characteristics
• Heat treatable for enhanced properties
• Compatible with major AM equipment manufacturers

APPLICATION AREAS

Medical and Orthopedic Implants

CoCrMo powder for medical device manufacturing:

• Hip Replacement Systems: Femoral stems, acetabular cups, modular heads
• Knee Prosthetics: Tibial trays, femoral components, patellar implants
• Spinal Implants: Pedicle screws, vertebral cages, spinal rods
• Shoulder and Elbow Implants: Glenoid components, humeral heads
• Custom Patient-Specific Implants: CT/MRI-based anatomical implants
• Revision Surgery Components: Complex geometry revision implants
• Trauma Plates and Screws: Load-bearing fixation devices
• Bone Grafts and Scaffolds: Porous lattice structures for osseointegration

Dental Applications

High-precision dental prosthetics:

• Dental Crowns and Bridges: Multi-unit fixed prostheses
• Removable Partial Denture Frameworks: RPD metal frameworks
• Implant Abutments: Custom angulated abutments
• Copings and Substructures: Metal frameworks for ceramic veneering
• Surgical Guides: Implant placement guides
• Orthodontic Appliances: Custom brackets and wires

Surgical Instruments and Tools

Durable medical instruments:

• Surgical cutting instruments and scalpels
• Arthroscopic instruments and shavers
• Orthopedic reamers and drills
• Biopsy punches and forceps
• Endoscopic tools and probes
• Retractors and clamps

Aerospace and High-Temperature Applications

Critical aerospace components:

• Gas turbine engine components (vanes, blades)
• Hot section parts with high wear resistance
• Fuel system components requiring corrosion resistance
• High-temperature fasteners and bushings
• Wear-resistant bearing surfaces
• Erosion-resistant components

Industrial and Mechanical Engineering

High-performance industrial parts:

• Valve seats and trim components for aggressive media
• Pump impellers and wear plates
• Sealing surfaces and bearing components
• Textile machinery parts
• Food processing equipment (corrosion resistance)
• Chemical processing industry components

Energy Sector Applications

Demanding energy industry components:

• Nuclear power plant components
• Oil and gas downhole tools
• Geothermal energy system parts
• High-temperature valve components
• Erosion-resistant turbine parts

Automotive and Racing

High-performance automotive components:

• Turbocharger components
• High-stress engine parts
• Racing transmission components
• Valve train components
• Performance exhaust system parts

Research and Development

Advanced materials research:

• Biomedical research and development
• New implant design validation
• Lattice structure optimization studies
• Wear and fatigue testing specimens
• Multi-material investigations
• Biocompatibility testing samples

Custom Manufacturing and Prototyping

Personalized medical solutions:

• Patient-specific anatomical models
• Pre-surgical planning models
• Complex geometry prototypes
• Low-volume custom production
• Rapid implant development
• Topology-optimized designs

  For bulk purchases, please contact us.
