Description
Graphene Ethanol Dispersion, Purity: 99.5%, Graphene: 1 wt%
This high-performance Graphene Ethanol Dispersion contains 1 wt% high-purity graphene (99.5%) suspended in ethanol, stabilized with a surfactant to ensure excellent colloidal stability and prevent aggregation. The dispersion is engineered for demanding applications in energy storage, printed electronics, coatings, and nanocomposites.
With flake diameters ranging from 2.0 to 12.0 µm and graphene thickness of just 0.6–1.2 nm, this formulation delivers exceptional electrical, thermal, and barrier properties, making it suitable for both research and scalable industrial uses.
Technical Specifications
| Property | Value |
|---|---|
| Graphene Purity (%) | 99.5 |
| Graphene Thickness (nm) | 0.6 – 1.2 |
| Flake Diameter (µm) | 2.0 – 12.0 |
| Appearance | Black Liquid |
| Concentration (wt%) | 1 (mg/mL) |
| Specific Surface Area | 600 – 1200 m²/g |
| Elemental Analysis (%C / %O) | 99.6 / <0.4 |
| Surfactant Present | Yes |
| Solvent | Ethanol |
Key Features
-
Contains 1 wt% high-purity graphene
-
Uniform dispersion in ethanol with excellent stability
-
High surface area and ultra-thin sheets
-
Great electrical and thermal conductivity
-
Ideal for coating, spraying, inkjet printing, and solution-based processing
-
Surfactant-stabilized for enhanced shelf life and usability
Applications
-
Printed electronics and conductive inks
-
Energy storage devices (battery and capacitor electrodes)
-
Anti-static and conductive coatings
-
Polymer-based nanocomposites
-
Corrosion-resistant layers
-
Flexible devices and transparent films
-
Graphene-based biosensors
Sem image of Graphene
FTIR spectrum of graphene produced by liquid phase exfoliation
Additional information
| Milliliter | 25 ml, 100 ml, 500 ml, 1000 ml |
|---|
