Hydrothermal Synthesis Autoclave Reactor with PPL Lined Vessel – 100 mL
The 100 mL Hydrothermal Synthesis Autoclave Reactor with PPL lining is designed for conducting high-pressure, high-temperature chemical reactions in a safe, controlled laboratory environment. The inner chamber is made of PPL (perfluoroalkoxy polymer), known for its excellent chemical stability, acid and alkali resistance, and corrosion durability, making it ideal for hydrothermal experiments involving aggressive or reactive materials.
The reactor is widely used in nanoparticle synthesis, crystal growth, material digestion, polymerization, and catalyst development. The smooth threading structure ensures easy opening and sealing, while the robust design offers strong airtightness under harsh conditions.
This reactor enables safe and reliable operation at elevated temperatures up to 250°C (with a max threshold of 280°C) and working pressures up to 3 MPa, making it suitable for a broad range of hydrothermal and solvothermal synthesis processes.
Technical Specifications
| Property | Value |
|---|---|
| Chamber Volume | 100 mL |
| Inner Lining Material | PPL (Perfluoroalkoxy polymer) |
| Maximum Operating Temperature | 250°C |
| Peak Temperature Tolerance | 280°C |
| Maximum Working Pressure | 3 MPa |
| Recommended Heating/Cooling Rate | 5°C/min |
| Resistance | Strong acid, base, and corrosion resistance |
| Seal | High airtightness, thread-lock |
Key Features
-
Simple to operate with smooth-thread lock design
-
High chemical resistance (acidic and basic media)
-
Corrosion-resistant and pressure-safe
-
Ideal for harsh reaction environments
-
Excellent sealing for stable internal conditions
-
Designed for precision-controlled hydrothermal reactions
Application Areas
-
Hydrothermal and solvothermal synthesis
-
Nanomaterials production and crystal growth
-
Catalyst synthesis and hydrothermal oxidation
-
Polymerization and hydrothermal decomposition
-
Organic compound digestion
-
Heavy metal dissolution and extraction
-
High-temperature crystallization and precipitation processes
-
Acid/base reaction chambers in material science labs
This product is suitable for laboratory-scale synthesis involving refractory materials, metal salts, organic chemicals, and advanced material research where extreme reaction conditions are required.
Important Note
Users should assess the suitability of this product for their intended use. NanographeneX Nanotechnology disclaims liability for any damages resulting from improper application or reliance on this information, except as mandated by law.
