Hydrothermal Synthesis Autoclave Reactor with PTFE Lined Vessel – 100 mL
The 100 mL PTFE-lined Hydrothermal Autoclave Reactor is designed for controlled high-temperature and high-pressure synthesis processes in laboratory environments. The internal chamber is made of PTFE (Polytetrafluoroethylene, also known as Teflon), which offers excellent chemical inertness, acid/base resistance, and corrosion durability, even when exposed to highly aggressive or reactive substances.
Ideal for applications in nanotechnology, crystal growth, polymerization, and catalyst development, this reactor enables experiments under precise thermal and pressure control. The unit supports safe continuous operation up to 180°C (maximum 240°C) and 3 MPa pressure, with a recommended heating/cooling rate of 5°C/min.
The PTFE lining makes this autoclave especially suitable for acidic and alkaline hydrothermal reactions, while the stainless steel outer shell ensures mechanical stability and long-term durability.
Product Specifications
| Component | Specification |
|---|---|
| Chamber Volume | 100 mL |
| Outer Body Material | 304 Stainless Steel |
| Inner Chamber Material | PTFE (Polytetrafluoroethylene) |
| Total Height | 160 mm |
| Outer Body Height | 113 mm |
| Outer Body Outside Dia | 63 mm |
| Outer Body Inside Dia | 49 mm |
| Outer Body Thickness | 7 mm |
| PTFE Chamber Height | 96 mm |
| PTFE Chamber Outside Dia | 49 mm |
| PTFE Chamber Thickness | 5 mm |
| Upper Cap Thickness | 40 mm |
| Upper Disc Thickness | 10 mm |
| Lower Disc Thickness | 10 mm |
| SS Rod Size | 8 × 200 mm |
| Max Operating Temperature | 180°C (Tolerance: 240°C) |
| Max Working Pressure | 3 MPa |
| Heating/Cooling Rate | Recommended 5°C/min |
Key Features
-
Simple and secure sealing with smooth-threaded design
-
Excellent resistance to strong acids and alkalis
-
High corrosion resistance under reactive conditions
-
Durable stainless steel outer body for mechanical stability
-
Ideal for small-scale high-pressure chemical synthesis
-
Suitable for hydrothermal and solvothermal reactions
Application Areas
-
Synthesis of nanomaterials and quantum dots
-
Hydrothermal crystal growth
-
Polymerization under pressure
-
Catalyst development and testing
-
Chemical digestion of organic and inorganic substances
-
Precipitation, decomposition, and oxidation processes
-
Dissolution of heavy metals and refractory compounds
-
Research-based chemical crystallization in academic and industrial labs
This reactor is a versatile tool for researchers and chemists working with sensitive reactions under extreme conditions, especially in fields requiring chemical purity and thermal/pressure tolerance.
Important Note
Please evaluate the compatibility of this reactor with your intended chemical processes. NanographeneX Nanotechnology assumes no liability for damage or loss arising from misuse, except as required by applicable law.
