Hydrothermal Synthesis Autoclave Reactor with PTFE Lined Vessel – 50 mL
This 50 mL Hydrothermal Synthesis Autoclave Reactor is specifically designed for small-scale, high-pressure and high-temperature chemical synthesis applications. Featuring a 304 stainless steel exterior and a PTFE (Polytetrafluoroethylene) inner chamber, it provides superior resistance to acidic, alkaline, and corrosive environments.
The PTFE lining ensures chemical inertness, making the reactor ideal for hydrothermal or solvothermal processes that require clean conditions. With a safe operating temperature of up to 180°C (maximum 240°C) and a pressure limit of 3 MPa, this compact reactor is suited for laboratory-scale research and precise experimentation.
Product Specifications
| Component | Specification |
|---|---|
| Chamber Volume | 50 mL |
| Outer Body Material | 304 Stainless Steel |
| Inner Chamber Material | PTFE (Polytetrafluoroethylene) |
| Total Height | 140 mm |
| Outer Body Height | 93 mm |
| Outer Body Outside Dia | 53 mm |
| Outer Body Inside Dia | 40 mm |
| Outer Body Thickness | 6.5 mm |
| PTFE Chamber Height | 78 mm |
| PTFE Chamber Outside Dia | 40 mm |
| PTFE Chamber Thickness | 5 mm |
| Upper Cap Thickness | 40 mm |
| Upper Disc Thickness | 10 mm |
| Lower Disc Thickness | 10 mm |
| SS Rod Size | 8 × 200 mm |
| Max Operating Temperature | 180°C (Tolerance: 240°C) |
| Max Working Pressure | 3 MPa |
| Heating/Cooling Rate | Recommended 5°C/min |
Key Features
-
Compact design ideal for lab-scale synthesis
-
Smooth threaded mechanism for secure sealing
-
Excellent resistance to strong acids and bases
-
Reliable corrosion resistance in reactive conditions
-
High temperature and pressure durability
-
Compatible with sensitive or corrosive reagents
Application Areas
-
Synthesis of advanced nanomaterials
-
Crystal growth and solid-state chemistry
-
Polymerization under hydrothermal conditions
-
Catalysis research and material processing
-
Sample digestion and heavy metal dissolution
-
Precipitation and decomposition reactions
-
Academic and industrial laboratory use
This small-volume PTFE-lined autoclave is a trusted tool in research institutions, R&D laboratories, and materials science applications requiring precise thermal and chemical control in sealed environments.
Important Note
All users should ensure compatibility with their specific experimental requirements. NanographeneX Nanotechnology assumes no responsibility for damage or loss arising from misuse. All warranties are limited to those required by law.
