Indium Tin Oxide (ITO) Nanopowder / Nanoparticles (In₂O₃:SnO₂ = 90:10, >99.99%, 20–70 nm)

Description

Indium Tin Oxide (ITO) Nanopowder / Nanoparticles (In₂O₃:SnO₂ = 90:10, >99.99%, 20–70 nm)

Indium Tin Oxide (ITO) Nanopowder is a transparent conductive oxide (TCO) nanomaterial, composed of 90 wt% Indium Oxide (In₂O₃) and 10 wt% Tin Oxide (SnO₂). With ultra-high purity (>99.99%), nanoscale particle size (20–70 nm), and specific surface area of 35 m²/g, ITO nanoparticles combine electrical conductivity with optical transparency.

Produced by the chemical precipitation method, these nanoparticles have an irregular morphology, low bulk density (~0.83 g/cm³), true density of 7.14 g/cm³, and a characteristic yellowish-green color. Their superior anti-radiation and antistatic performance make them essential in electronics, optoelectronics, and energy applications.

Technical Properties

• Composition: In₂O₃:SnO₂ = 90:10 (wt%)

• Purity: >99.99% (ICP–AES verified)

• Average Particle Size (APS): 20–70 nm (BET & TEM tested)

• Specific Surface Area (SSA): 35 m²/g

• Color: Yellowish green

• Morphology: Irregular

• Bulk Density: ~0.83 g/cm³

• True Density: 7.14 g/cm³

• Synthesis Method: Chemical Precipitation

Certificate of Analysis (ppm)

Technology Test Methods

• Particle Size: BET surface area analysis + TEM imaging

• Purity: ICP–AES method

Applications

Indium Tin Oxide Nanopowder (ITO) is a critical functional nanomaterial widely used in transparent conductive and protective technologies:

• Transparent Conductive Materials: Conductive glues, coatings, and films.

• Optoelectronics: LCD, LED, OLED, and touchscreens.

• Solar Energy: Transparent electrodes in photovoltaic cells.

• Radiation Protection: Anti-radiation coatings and devices.

• Infrared Protection: Infrared (IR) shielding for energy-efficient windows and devices.

• Antistatic Coatings: Applied to glass, polymers, and electronics.

Safety & Handling

• Nanoparticles should be handled in a controlled environment.

• Use protective equipment; avoid inhalation and ingestion.

• Store in sealed containers, away from light, moisture, and static sources.
