Description
Lanthanum Hexaboride (LaB₆) Micron Powder
Purity: 99.99%
Particle Size: 1–20 µm
Lanthanum Hexaboride (LaB₆), also known as lanthanum boride, is a refractory ceramic material renowned for its exceptional thermionic emission properties, low work function (~2.4 eV), and high chemical and thermal stability. Our high-purity LaB₆ micron powder (99.99%) with controlled particle size (1–20 µm) is ideally suited for advanced applications in high-temperature electron emission devices, X-ray diffraction calibration, and materials science research.
Due to its excellent electrical conductivity and high melting point, LaB₆ is widely used in hot cathodes, electron microscopes, and as a reference material in analytical instruments. It also finds utility in radar, aerospace, and infrared technologies where performance in extreme environments is critical.
Technical Properties:
| Property | Value |
|---|---|
| Purity (%) | 99.99 |
| Average Particle Size (µm) | 1–20 |
| Density (g/cm³) | 2.7 |
| Melting Point (°C) | 2210 |
| Color | Dark Violet-Black |
| Crystal Structure | Cubic |
| Work Function (eV) | ~2.4 |
| Thermal Stability | Excellent |
| Electrical Conductivity | High |
Applications:
-
Hot cathodes in electron emission systems (TEM, SEM, microwave tubes)
-
Coating material in thermionic emitters and vacuum electronic devices
-
X-ray diffraction calibration standard (size/strain reference)
-
Infrared optics and radar systems
-
Aerospace components requiring high thermal resistance
-
Electronics industry for cathodic arc deposition and advanced sensors
