Niobium (Nb) Nanopowder / Nanoparticles (99.9%, 50 nm, Metal Basis)
Purity: 99.9% (metal basis)
Appearance: Grey metallic powder
Average Particle Size (APS): 50 nm
Particle Size Distribution: TEM D10: 5 nm; D50: 50 nm; D95: 80 nm
Specific Surface Area (SSA): 30–40 m²/g
Shape: Spherical
Manufacturing Method: Laser evaporation
Technical Properties
| Property | Value |
|---|---|
| Purity (%) | 99.9 (metal basis) |
| APS (nm) | 50 (TEM D10: 5 nm; D50: 50 nm; D95: 80 nm) |
| SSA (m²/g) | 30–40 |
| Shape | Spherical |
| Manufacturing Method | Laser evaporation |
Elemental Analysis (%)
| Nb | Cu | Fe | Si | Al | Ni | S | P | Zn | C |
|---|---|---|---|---|---|---|---|---|---|
| 99.9 | 0.01 | 0.03 | 0.01 | 0.01 | 0.01 | 0.002 | 0.003 | 0.01 | 0.002 |
Applications
Electronics: Used in capacitors, superconducting materials, and advanced semiconductor components.
Energy storage: Electrode material for high-performance lithium-ion and solid-state batteries.
Metallurgy: Alloying element in stainless steel and superalloys for strength and corrosion resistance.
Medical applications: Potential use in biomedical implants and devices due to high biocompatibility.
Catalysis: Active phase in hydrogenation and other catalytic reactions.
Thin films & coatings: Applied in PVD/CVD processes for high-performance coating layers.
Additional information
| Gram | 25 g, 100 g |
|---|
