Silicon Carbide (SiC) Nanopowder / Nanoparticles – Beta Phase (99.5+%, 790 nm)
Silicon Carbide (SiC) nanoparticles, in the Beta (cubic) phase, are advanced ceramic materials renowned for their extreme hardness, thermal conductivity, and chemical stability. With a purity of 99.5+%, and an average particle size of 790 nm, this material is engineered for high-performance applications in refractories, ceramics, abrasives, and high-temperature components.
SiC features a density of 3.22 g/cm³, Mohs hardness of 9.5, and a decomposition temperature of 2973 K, making it one of the most durable and reliable ceramic compounds available. Its excellent thermal expansion coefficients and compressibility also make it a critical material in electronics, composites, and aerospace engineering.
Technical Properties
-
Chemical Formula: SiC
-
Crystal Phase: Beta (Cubic)
-
Purity: 99.5+%
-
Average Particle Size (APS): 790 nm
-
Density: 3.22 g/cm³
-
Decomposition Temperature: 2973 K
-
Mohs Hardness: 9.5
-
Thermal Expansion Coefficient (373 K): 6.7 × 10⁻⁶
-
Thermal Expansion Coefficient (1173 K): 3.0 × 10⁻⁶
-
Heating Power: 30.34 KJ/mol
-
Compressibility Coefficient: 0.2 × 10⁻⁶
Elemental Analysis (%)
-
Free C: 0.05
-
Fe: 0.057
-
Al: 0.018
-
Ca: 0.05
Applications
Silicon Carbide Nanopowder (Beta phase) is widely applied in advanced ceramic, electronic, and high-temperature technologies:
-
Refractory Applications: As a hard, high-grade refractory material.
-
Advanced Ceramics: For ceramic bearings, textile ceramics, high-frequency ceramics, and engine parts.
-
Electronics: Used in hard discs, semiconductor supports, and multichip modules.
-
Abrasives & Polishing: Applied in grinding wheels, polishing compounds, and surface finishing.
-
High-Temperature Components: Used in valves, spray nozzles, and fluid transport parts.
-
Composite Reinforcement: Enhances mechanical strength, wear resistance, and heat tolerance.
Safety & Handling
-
Store sealed under vacuum, in a cool and dry environment.
-
Avoid exposure to air and mechanical stress.
-
Handle with proper protective equipment to prevent inhalation or ingestion.
