Description
Titanium Nitride (TiN) Nanopowder/Nanoparticles – Purity: 99.5+%, Size: 800 nm, Cubic Phase
Product Overview
Titanium Nitride (TiN) Nanopowder is a black, cubic-phase ceramic nanomaterial known for its exceptional hardness, high melting point, and excellent thermal and electrical conductivity. Synthesized via plasma arc vapor phase techniques, this material maintains a particle size of approximately 800 nm and a true density of 5.2 g/cm³. Thanks to its chemical stability and wear resistance, TiN nanoparticles serve critical roles across both industrial and biomedical domains.
Technical Properties
| Property | Value |
|---|---|
| Purity (%) | 99.5+ |
| Average Particle Size (nm) | 800 |
| Color | Black |
| True Density (g/cm³) | 5.2 |
| Melting Point (°C) | 2950 |
| Crystal Phase | Cubic |
| Manufacturing Method | Plasma arc vapor phase |
Elemental Composition (%)
| Ti | C | Fe | Si |
|---|---|---|---|
| 77.80 | 0.0002 | 0.0015 | 0.0018 |
Storage Conditions
TiN nanopowder should be stored in vacuum-sealed containers, in a dry, cool environment, and kept away from air exposure to prevent oxidation and aggregation.
Applications
Titanium Nitride nanoparticles are utilized in a diverse range of high-performance applications:
-
Biomedical Materials: Used in prostheses, dental implants, and artificial limbs due to its biocompatibility and resistance to bodily fluids.
-
Cutting Tools and Molds: Acts as a wear-resistant coating to improve tool life and performance.
-
Plastic Molds: Enhances the surface durability and heat resistance of mold components.
-
Microelectronics: Functions as a diffusion barrier and gate electrode material in MOS transistors.
-
Schottky Diodes: Serves as a low-barrier metal contact due to its high electrical conductivity and stability.
-
Surface Engineering: Applied in thin films for reflective coatings, optical filters, and anti-corrosion surfaces.
Additional information
| Gram | 25 g, 100 g, 500 g, 1000 g |
|---|
