Description
Tungsten (W) Nanopowder / Nanoparticles – 99.95+%, 70 nm, Metal Basis
Our Tungsten (W) Nanopowder / Nanoparticles are produced using the electrical explosion method, ensuring uniform particle distribution and high purity for advanced applications. With a purity of 99.95+% (metal basis) and an average particle size of 70 nm (as determined by SEM), these nanoparticles offer excellent electrical, thermal, and mechanical properties.
Tungsten nanoparticles are ideal for use in aerospace alloys, high-performance electronics, heat-resistant coatings, and protective materials. Their high density, exceptional hardness, and thermal stability make them a preferred choice in demanding industrial applications.
Technical Specifications
| Property | Value |
|---|---|
| Purity (Metal Basis) | 99.95+% |
| Average Particle Size (APS) | 70 nm (50% = 70 nm, 25% < 70 nm, 25% > 70 nm, 0.5% up to 100–200 nm) |
| Specific Surface Area (SSA) | 20 m²/g |
| Color | Black |
| Bulk Density | 3.5 g/cm³ |
| True Density | 19.3 g/cm³ |
| Production Method | Electrical Explosion |
Elemental Analysis (ppm)
| Element | Content |
|---|---|
| W | ≥99.95% |
| Mo | ≤30 |
| Al | ≤14 |
| As | ≤10 |
| Ca | ≤10 |
| Fe | ≤20 |
| Mg | ≤10 |
| Si | ≤10 |
| Na | ≤9 |
| Ni | ≤6 |
| Mn | ≤6 |
| Pb | ≤5 |
| K | ≤76 |
Properties & Handling
Tungsten nanoparticles are highly reactive and flammable. They must be handled with care, avoiding rapid movement, mechanical vibrations, or impacts. Exposure to air, moisture, heat sources, and sunlight should be strictly avoided to prevent oxidation, agglomeration, and degradation.
Storage Recommendation:
Store in a sealed vacuum or inert atmosphere.
Keep in a cool, dry, and dark environment.
Avoid mechanical stress and exposure to open air.
Applications
Aerospace Alloys – High-strength, heat-resistant components.
Electronic Packaging – Thermal management and conductive materials.
Heat Sinks & Thermal Management – Superior heat dissipation.
Protective Coatings – Wear and corrosion resistance.
Sintering Additives – Improves mechanical strength of composite materials.
Vacuum & Electrical Contacts – Used in switchgear, circuit breakers, and vacuum systems.
Sensors & Microelectronics – Gas sensors, microelectronics films, and waveguide layers.
Armor & Defense Materials – Anti-armor applications due to extreme density.
Additional information
| Gram | 25 g, 100 g, 500 g |
|---|
