Description
Aligned Multi Walled Carbon Nanotubes (MWCNTs)
Purity: > 95% Outside Diameter: 10–20 nm Length: 20–90 µm
Aligned Multi Walled Carbon Nanotubes (MWCNTs) are composed of multiple concentric single-walled carbon nanotubes, perfectly aligned and bundled in a uniform orientation. This structural order enables superior charge transfer, mechanical strength, and thermal stability—offering enhanced functionality in electronics, energy storage, and nanocomposites.
With their extended length (20–90 µm) and excellent electrical conductivity (~1300 S/cm), these MWCNTs are ideal for high-performance applications such as lithium batteries, supercapacitors, solar panels, sensors, and nanostructured materials. Produced via the CVD method, our nanotubes offer both quality and cost-efficiency for your R&D and production needs.
Technical Properties
| Property | Value |
|---|---|
| Purity | > 95 wt% |
| Color | Black |
| Outside Diameter | 10–20 nm |
| Inside Diameter | 5–10 nm |
| Length | 20–90 µm |
| Tap Density | 0.05 g/cm³ |
| True Density | 2.2 g/cm³ |
| Specific Surface Area | 170 m²/g |
| Ash Content | 2 wt% |
| Electrical Conductivity | 1300 S/cm |
| Ignition Temperature | 661 °C |
| Manufacturing Method | CVD |
Applications
Aligned MWCNTs are widely applicable in a broad range of industries due to their structure and properties:
-
Drug Delivery
-
Biosensors
-
Nanotube-Reinforced Composites
-
Catalysis
-
Nanoprobes
-
Hydrogen Storage
-
Lithium-Ion Batteries
-
Gas Discharge Tubes
-
Flat Panel Displays
-
Supercapacitors
-
Transistors
-
Solar Cells
-
Photoluminescent Materials
-
Nanostructured Templates
